49 inch Embedded dustproof industrial control industrial LCD screen industrial quality all-in-one machine
Intelligent Industrial LCD Screen: Enhanced Visualization and Stability for Modern Applications
Against the backdrop of evolving industrial automation, smart manufacturing, and control system upgrades, intelligent Industrial LCD Screen are gaining increasing preference among industry users due to their large high-definition screens, stable performance, and high expandability. They not only provide a broader field of view for operation and monitoring but also deliver superior visual and interactive experiences in information-intensive scenarios.
Large Screen for Intuitive Visualization
Equipped with a large high-definition display, supporting resolutions up to 1920×1080 or higher, and utilizing industrial-grade A-Spec LCD panels for sharp, vivid, and true-to-life images without color shift or flickering.
The large screen design is ideal for displaying complex data and managing multiple concurrent Win, making it widely suitable for industrial control rooms, data monitoring centers, digital workshops, and energy dispatch systems.
IPS wide-view technology ensures clear picture quality from various viewing angles, particularly beneficial for multi-person viewing and collaborative operations, thereby enhancing overall work efficiency.
Industrial-Grade Quality and Robust Stability
The chassis is constructed from high-strength cold-rolled steel, offering excellent impact resistance, corrosion resistance, and tolerance to high and low temperatures, operating reliably in environments from -10°C to 60°C.
The front panel meets IP65 dustproof and waterproof standards, ensuring stable performance in dusty or humid settings such as workshops, warehouses, and outdoor installations.
Rational internal structural design incorporates silent fans or all-aluminum passive cooling systems, maintaining thermal stability during prolonged operation and effectively extending the product's service life.
Multiple Interfaces for Strong Compatibility
Offers a rich selection of interfaces for connecting external devices such as cameras, printers, barcode scanners, and PLC control systems, meeting the integration needs of various industries.
Beyond common ports, supports expandable Wi-Fi, Bluetooth, and 4G modules to adapt to different networking and remote control scenarios.
Diverse Application Scenarios
Intelligent Industrial LCD Screen are deployed in numerous fields, including:
Manufacturing: Serving as production line control terminals, equipment status displays, and parameter input panels.
Transportation: Applied in rail transit dispatch, vehicle information query systems, and self-service ticket check systems.
Healthcare: Used for patient room care terminals, information collection, and data interaction.
Building Management: Employed in smart building security monitoring and access control system display interfaces.
| LCD Panel Parameters |
Screen Size |
49 Inch |
| Display Area |
1073.8 mm.(Height) X 604.1 (Width)mm. |
| Aspect Ratio |
16 : 9 |
16 : 9 |
| LCD Type |
a-Si TFT-LCD Monitor |
a-Si TFT-LCD Monitor |
| Maximum Resolution |
1920 X 1080 |
3840 X 2160 |
| Display Color |
16.7m , 72% NTSC |
1.06B, 74% NTSC |
| Brightness |
300cd/m² |
400cd/m² |
| Contrast Ratio |
1200 : 1 |
1000 :1 |
| Viewing Angle (Up/Down/Left/Right) |
89°/89°/89°/89° (Type)(CR≥10) |
89°/89°/89°/89°(Type)(CR≥10) |
| Response Time |
8ms |
6ms |
| LCD Panel Lifespan (Hours) |
60,000(Hour.) |
| Field Frequency |
60Hertz |
Internal computer configuration
(Choose one of two) |
CPU |
i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz |
I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz |
| Graphics Card |
Integrated Graphics Card Intel® HD 4600 |
Integrated Graphics Card Intel® HD 530 |
| RAM |
4GB |
8GB |
| Storage Memory Capacity |
128GB |
256GB |
| OS |
Linux |
Linux |
| Wi-Fi Built-in |
Speed 150Mbps 802.11n wifi Integrated |
Speed 150Mbps 802.11n wifi Integrated |
| Media Format |
Video Format |
wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio Format |
MP3, WMA |
| Photo Format |
BMP, JPEG, PNG, GIF etc. |
| Onboard Interface |
Network port |
RJ45 X 1, 10M/100M Adjustable Ethernet |
| HDMI |
1 |
| USB |
4 |
| Power |
Power Supply |
Alternating Current 100V~240V, 50/60Hz |
| Maximum Power Loss |
≤ 90 Watt |
| Standby Mode Power Loss |
< 1 Watt |
| Features |
Operating Temperature |
0℃ ~ 50℃ |
| Storage Temperature |
Below 10℃ ~ +60℃ |
| Package Size |
Device Dimensions |
1144 X 674 X 66.9 mm. |
| Net Weight |
29 Kilogram |
| Package Size |
137.5 X 14.5 X 84.5Centimeter |
| Gross Package Weight per Unit |
32 Kilogram |
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
